8 Maintenance RJ-901C/RJ-900C Maintenance Manual
8-6
8.4 Lubrication/Bonding
This section covers the lubrication/bonding information.
After disassembling/assembling this plotter, always perform necessary lubrication/bonding according to
Table 8-3"Lubricant List"(p.6).
CAUTION
Only use specified lubricants and greases. The use of unauthorized lubricants and greases
may damage the components and shorten the plotter life.
Table 8-3 Lubricant List
Parts Item Manufacturer Type Explode
d view
Cover section
(CAT5009-
00)
Roll receiver
(L, R)
Apply to the top
cover contacting
surface.
Dow Corning
Asia Ltd.
EM-60L
Front cover
support pin L
Apply to the top
cover contacting
surface.
Dow Corning
Asia Ltd.
EM-60L
CR section
(CAT5004-
00)
Cursor guide Apply to the front
surface.
Mitsubishi Super multi-dia
tetrat No.32
Pressure
shaft bearing
Apply to the
peripheral surface.
Dow Corning
Asia Ltd.
EM-60L
Pressure
shaft stopper
Apply to the
pressure lever
springs.
Dow Corning
Asia Ltd.
EM-60L
Head section
(CAT5003-
00)
Head cable Affix to each cable
(for locating and
holding)
Not specified 10mm- width
double faced
tape
Cable guide
section
(CAT5007-
00)
CR cable Affix to each cable
(for locating)
Not specified 10mm-width
double faced
tape
Tube guide Affix to the tube
guide (for
locating)
Not specified 10mm-width
double faced
tape
Others Screw Apply to the area
screw-locking
agent is applied.
Three Bond Co.,
Ltd.
1401 -
