5 Self-Diagnosis Mode RJ-901C/RJ-900C　 Maintenance Manual
5-68
5.9.7 General Endurance Menu
This menu performs the general endurance running.
In this menu, various driven systems operation can be performed according to the value set..
The available settings are shown below.
TIP
• In the general endurance menu, the following operations are performed as one cycle of endurance
running
• Carriage stroking: 1 stroke
• Media feed: 1 cycle
• If the number of endurance running cycles is set to -1, the carriage continuously repeats stroking
until cancel input is given from the operation panel.
• The maximum counter value for endurance running cycles is 99999999 (up to 8-digit number). If
the number of cycles exceeds the maximum value, the counter is reset to 0.
Table 5-22 Set Items in General Endurance Menu
Set item Contents Set value Remark
Running speed (CW,
CCW)
Set the carriage running
speed (CW direction,
CCW direction)
100, 120, 160, 200 Unit: cps
Media feed amount Set the media feed
amount per cycle
0.1 to 100 Unit: mm
Number of endurance
running cycles
Set the number of
endurance running cycles
-1 to 10000
CW-speed
CCW-speed
Media feed amount
Endurance count
[Enter] key
[Enter] key
[Enter] key
[Enter] key
[Enter] or [Cancel] key
Performing endurance running
To Next Page
