About this Manual RJ-901C/RJ-900C Maintenance Manual
(3)
About this Manual
1. Purpose and Target Readers
This manual explains preparations needed before maintaining and checking operations for MUTOH Full
Color Ink Jet Plotter (RJ-901C and RJ-900C).
This is a common maintenance manual for RJ-901C and RJ-900C.
If not mentioned, the descriptions are common for the both models.
This manual is prepared for the maintenance personnel of this plotter.
Before using this plotter, fully understand the contents and directions in this manual.
2. Manual Configuration
Section Contents
1 Safety Instructions Explains types of warnings, cautions and warnings labeled on the plotter
for the both operators of the plotter and maintenance personnel.
2 Product Overview Explains the features, part names, and functions of the plotter.
3 Specifications Explains the specifications of the plotter.
4 Parts Replacement Explains the procedures of replacement and removal of the service parts
of the plotter.
5 Self-Diagnostic Mode Explains the self-diagnostic functions of the plotter.
6 Maintenance Mode2 Explains the maintenance mode2 of the plotter.
7 Adjustment Explains the adjusting procedures of the plotter parts.
8 Maintenance Explains daily maintenance of the plotter.
9 Troubleshooting Explains troubles that may occur when using the plotter and how to
solve them.
10 Appendix Explains the maintenance information and the exploded views for this
plotter.
Use the built-in self-diagnostic program to locate a defective part and adjust/
check during maintenance.
