4 Parts Replacement RJ-901C/RJ-900C　 Maintenance Manual
4-10
4. Remove the L side cover roll receiver side screw (tapping screw M4 × 12, P tight binding black: 1pcs).
5. Remove the L side cover.
6. To reassemble the unit, reverse the removal procedure.
No. Part name
1L side cover
2 Roll receiver side screw
2
1
