RJ-901C/RJ-900C 　 Maintenance Manual 4 Parts Replacement
4-29
NOTE
When handling the PF scale, note the following.
• Do not damage or bend the PF scale. Do not touch the peripheral surface of the PF scale.
• Make sure that no double-sided tape remains on the slit mounting flange.
4. Perform adjustments by following the instructions in "7.2 Adjustment Item" p.7-3.
To Next Page
