Main Components and Their Functions
Phaser® 6128MFP Multifunction Printer
16
Main Components and Their Functions
This section includes:
• Front View on page 16
• Rear View on page 17
• Internal View on page 17
Front View
1. Automatic document feeder (ADF) tray
2. Output tray
3. Button for opening the front door
4. Power switch
5. Side door
6. Manual feed slot
7. Paper tray
8. Front door
9. Control panel
1
2
3
4
5
6
7
8
9
6128mf
p
-037
