Xerox Phaser 6128MFP User Manual

Description of Menu Items
Phaser® 6128MFP Multifunction Printer
114
Print Language
Use this menu to specify PCL settings.
Network Setup
Specifies printer settings affecting jobs sent to the printer through a network port.
• The settings in the Network Setup menu cannot be set when entering this menu
during printing.
• You need to restart the printer to activate the new settings. After making the settings,
turn off the printer and then turn it on again.
Item Description
Paper Size Specifies the default paper size.
Orientation The paper printing direction can be selected from Portrait and Landscape.
The default is Portrait.
Font Specifies the font used. The default is Courier.
Symbol Set Specifies the font for symbols. The default is ROMAN-8.
Font Size Specifies the default font size. Available only for typographic fonts.
Font Pitch Specifies the character spacing. The default is 10.00. You can specify a
value between 6.00 and 24.00 in increments of 0.01.
Form Line Specifies the form line (the number of lines per form). The default is 64. You
can specify a value between 5 and 128 in increments of 1.
Quantity Specifies the copies to be printed. You can specify a value between 1 to
999. The default is 1.
Image Enhance Selects whether to perform image enhancement.
Image enhancement is a feature that makes the boundary line between
black and white smoother in order to decrease jags and enhance the visual
appearance. The default is On.
Hex Dump Specifies whether to print the data sent from a computer in the ASCII code
corresponding to the hexadecimal notation format in order to check the
data contents. The default is Disable.
Draft Mode Specifies whether to print in draft mode. The default is Disable.
Line
Termination
Specifies line termination.
• Off
Line termination commands are not added.
• Add-LF
The Line Feed command is added.
• Add-CR
The Carriage Return command is added.
• CR-XX
The Line Feed and Carriage Return commands are both added.
Default Color Specifies the default color mode.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
