Xerox Phaser 6128MFP - Rear View; Internal View

Main Components and Their Functions
Phaser® 6128MFP Multifunction Printer
17
Rear View
Internal View
1. ADF cover
2. Memory slot door (open)
3. USB port
4. Network connector
5. Phone out
6. Line in
7. Power reset (circuit breaker)
8. Power socket
1. Fuser
2. Imaging unit
3. Toner cartridges
4. Transfer unit
5. Button for opening the front door
1
2
3
4
5
6
7
8
6128mf
p
-038
6128mfp-039
2
1
3
4
5
