7. For Login, Password, and Retype Password, type the login credentials for the LDAP server.
8. For Maximum Number of Search Results, type a number. The default is 50.
9. To define a timeout, click Search Timeout, then select an option:
• Use LDAP Server Timeout: This option uses the current settings for the LDAP server.
• Specify Timeout: This option sets a specific duration before the LDAP search times out.
Note: If you experience trouble retrieving results from your LDAP server, use the
Specify Timeout option.
10. If you selected Specify Timeout, for Timeout, type the number of seconds that the printer waits
before it stops the LDAP search.
11. To include more LDAP servers in your searches, for LDAP Referrals, select the toggle button.
12. If you enabled LDAP Referrals, for Maximum Number of LDAP Referral Hops, type the maximum
number of hops.
13. Click OK.
CCoonnffiirrmmiinngg LLDDAAPP UUsseerr MMaappppiinnggss
LDAP servers display various results, depending on how they implement mappings. You can map LDAP
fields to fields on your printer, and edit current map settings for fine-tuned server search results.
1. In the Embedded Web Server, log in as administrator, then click Connectivity.
2. In the Protocols area, click LDAP.
3. Click LDAP User Mappings.
4. In the Search area, for User Name, type a user name, then click Search.
5. For Search Conditions, click the menu for each field, then remap the field as needed. The schema
on the LDAP server defines the headings.
6. Click OK.
Note: If the user mapping is incorrect, an LDAP search in the Embedded Web Server can work
properly, but authentication at the printer still fails.
CCoonnffiigguurriinngg LLDDAAPP AAuutthheennttiiccaattiioonn
1. In the Embedded Web Server, log in as administrator, then click Connectivity.
2. In the Protocols area, click LDAP.
3. Click LDAP Authentication.
4. Click Authentication Method, then select an option.
5. To specify a user name as a search parameter, for Common Name, type the user name for the
authorized user.
6. To specify a login name as a search parameter, for Login User Name, type the login name for the
authorized user.
7. To add a text string to a user name, for Use Added Text String, click the toggle button.
52
Xerox
®
VersaLink
®
Series Multifunction and Single Function Printers
System Administrator Guide
Network Connectivity
