Raw TCP/IP Printing
Raw TCP/IP is used to open a TCP socket-level connection over Port 9100, and stream a print-ready
file to the printer input buffer. It then closes the connection either after sensing an End Of Job
character in the PDL or after expiration of a preset timeout value. Port 9100 does not require an LPR
request from the computer or the use of an LPD running on the printer. Raw TCP/IP printing is
selected in Windows as the Standard TCP/IP port.
Note: Enable TCP/IP before enabling Raw TCP/IP printing.
CCoonnffiigguurriinngg RRaaww TTCCPP//IIPP SSeettttiinnggss
1. In the Embedded Web Server, log in as administrator, then click Connectivity.
2. In the Protocols area, click Port 9100.
3. For Port, enable toggle button.
4. For Port Number, ensure that the Port is set to 9100.
5. For PJL, enable the toggle button.
6. Click Print Mode, then select an option.
7. For Timeout, type the number of seconds.
8. For TBCP Filter, enable the toggle button.
9. To use TCP-MSS, enable the toggle button, then for IPv4 Subnet 1, IPv4 Subnet 2, and IPv4
Subnet 3, type the IP addresses and ports.
10. Click OK.
56
Xerox
®
VersaLink
®
Series Multifunction and Single Function Printers
System Administrator Guide
Network Connectivity
