Xerox WORKCENTRE PE 220 User Manual

Spare Parts List
Workcentre PE 220 11/05 5-15
PL 7 Fuser Unit
Item Part Number Description Qt’y Remark
0 101N01381 FUSER_220V 1
0 101N01380 FUSER_110V 1
1 FRAME-P-FUSER 1
2 COVER-M_FUSER 1
3 019N00839 HOLDER-M-EXIT R 2
4 007N01377 GEAR-EXIT_DRV17 1
5 HOLDER-M-EXIT F/DOWN 3
6 SPRING-CS 2
7 013N13843 BEARING-PRESSURE/R 2
8 GUIDE-M-INPUT 1
9 022N01611 ROLLER-PRESSURE 1
10 022N01610 ROLLER-HEAT 1
11 007N01205 GEAR-FUSER, Z37 1
12 016N00282 BUSH-M-HR L 1
13 016N00262 BUSH-M-HR R 1
14 122N00245 LAMP-HALOGEN_220V 1
14 122N00246 LAMP-HALOGEN_110V 1
15 ROLLER-M-EXIT MAIN 3
16 ROLLER-M_EXIT FR 3
18 009N01522 SPRING-CS 3
19 130N01417 THERMISTOR-NTC 1
20 130N01411 THERMOSTAT-150 1
21 152N11628 CBF HARNESS-FUSER JOINT 1
22 152N11626 CBF HARNESS-FUSER (220V) 1
22 152N11631 CBF HARNESS-FUSER (110V) 1
23 PADDLE 2
24 GEAR EXIT-DR38/25 4
25 WASHER-PLAIN 4
26 E-CLIP 1
27 STRIPPER FINGER 1
27-1 009N01523 SPRING ETC-STRIPPER FINGER 4
27-2 019N00840 HOLDER_M_PLATE STRIPPER FINGER 4
27-3 PLATE-P-STRIPPER FINGER 4
28 COVER-M-GUIDE EXIT 1
29 COVER-M-SAFETY FUSER 1
30 LEVER-M_ACT EXIT 1
31 SPRING ETC-TR(KOR) 1
32 HOLDER-M_ACTUATOR 1
33 CBF HARNESS-THERMISTOR 1
34 LEVER-M-ACTUATOR JAM 1
35 PMO-BUSHING TX(B4) 1
36 SPRING ETC-TORSION DOC (CC2-F) 1
