Spare Parts List
Workcentre PE 220 11/05 5-17
PL 8 Main Frame Assembly
Item Part Number Description Qt’y Remark
0 ELA HOU-FRAME LOWER 1
1 FRAME-M-BASE 1
2 015N00560 MEA UNIT-PLATE KNOCK_UP 1
2-1 015N00561 PLATE-M-KNOCK_UP 1
2-2 SHAFT-P-CORE 1
2-3 PMO-IDLE KNOCK UP MP 2
2-4 019N00835 MPR-PAD KNOCK UP MR 1
3 009N01516 SPRING ETC-TORSION DEVE_L 1
4 009N01517 SPRING ETC-TORSION DEVE_R 1
5 126N00247 ELA HOU-RX DRIVE 1
5-1 BRACKET-P-GEAR 1
5-2 BRACKET-P-MOTOR 1
5-3 GEAR-RDCN 139/83 1
5-4 127N07405 MOTOR STEP-MAIN 1
5-5 PMO-IMPELLER_DRV 1
6 PAPER PATH ASSEMBLY (REFER TO PL 6
)1
7 026N00764 ADJUST-M-CASSETTE_R 1
8 026N00765 ADJUST-M-CASSETTE_L 1
9 007N01178 GEAR-PINION 1
10 017N00251 FOOT-FRONT 2
11 007N01371 GEAR-RDCN 113/83 1
12 007N01372 GEAR-OPC DR 76/38/29 1
13 007N01373 GEAR-FUSER DR 63/35 1
14 007N01374 GEAR-FEED DR 41 1
15 120N00481 LEVER-M-ACTUATOR_EMPTY 1
16 009N01513 SPRING ETC-TORSION DOC (CC2-F) 1
17 115N00857 GROUND-P-OPC 1
18 NOT USED
19 CAP-M-MOTOR 1
20 009N01518 SPRING ETC-CS-CHARGE APOLLO 2
21 CRUM ASSEMBLY 1
21-1 003N00973 PLATE-M-HINGE 1
21-2 SPRING ETD-FEED 1
21-3 015N00564 PLATE-M-CRUM 1
21-4 TERMINAL-CRUM 8
21-5 TERMINAL-M_BLOCK 1
21-6 140N63043 PBA-CRUM_P 1
22 127N01453 FAN-DC 1
To Next Page
