General Procedures and Information
Workcentre PE 220 11/05 6-23
OPE (Operational Panel Equipment)
1) OPE Panel
OPE Panel has a MICOM Chip on it and communicates with Main CPU using Serial com-
munication Line (SIO). OPE Panel consists of Micom, Key Matrix Part, LED Driving Part
and LCD Part.
2) Key Description
3) LCD Part
- Number of Characters: 16 Characters x 2 line
• Clock, Date display
• System Status display
• Alarm, Error Message display
• Function Dialog Message display
Table 1:
No Part Feature Function
1 Common 3*4Key Dialling and Option Input
Start
Stop/Clear
Menu Option select
Upper Level Return to
upper level menu
Enter Option select/
Execute
Next menu or Next
option item
Previous menu or Pre-
vious option item
2 Save Toner Save TONER SAVE MODE select
3 Copy Reduce/Enlarge Select ZOOM ratio when copy
No.of Copies Select the number of copies
Original Type Change Copy Modes (Text,Text/Photo,Photo)
Darkness Change the Darkness of the Copied image (Light/Normal/Dark)
Favourite Copy Select one of the predefined Copy templates.
4 Fax STANDARD>FINE>SUPER
FINE>PHOTO>COLOR
Phone Book Search the user defined Phone number.
Broadcasting When sending FAX data to many place in the same time.
Manual Dial Manual Dial
Redial / Pause Last number Redial / Pause
5 Scan Scan to select [scan to PC], [scan to FAX], [scan to E-mail] function
