Spare Parts List
Workcentre PE 220 11/05 5-5
PL 2 ADF Assembly
Item Part Number Description Qt’y Remark
0 002N02441 ELA HOU-ADF 1
1 002N02444 ELA HOU-ADF LOWER 1
1-1 COVER-M-ADF LOWER 1
1-2 002N02445 ELA HOU-ADF MOTOR 1
1-2-1 GEAR-IDLE 35 ADF 3
1-2-2 007N01369 GEAR-CLUTCH 39 1
1-2-3 GEAR-SWING 31/20 ADF 1
1-2-4 GEAR-58/25 ADF 1
1-2-5 007N01370 GEAR-40/21 ADF 2
1-2-6 BRACKET-P-MOTOR 1
1-2-7 MOTOR STEP-ADF 1
1-2-8 IMPELLER-ADF 1
1-2-9 BRACKET-M-GEAR 1
1-3 140N63041 PBA SUB-ADF 1
1-4 GROUND-P-ADF 1
1-5 CBF HARNESS-ADF 1
1-6 ROLLER-DRIVE 1
1-7 013N13842 PMO-BUSH 4
1-8 007N01368 SHAFT-M-FEED GEAR 38 1
1-9 RING-C 1
1-10 130N01413 PMO-ACTUATOR SCAN SENSOR 1
1-11 009N01512 SPRING-CS 3
1-12 115N00856 MEC-BRUSH ANTISTATIC 1
1-13 009N01513 SPRING ETC-TORSION DOC (CC2-F) 3
1-14 015N00559 PLATE-M_WHITE BAR 1
1-15 PMO-ACTUATOR DOC SENSOR 1
1-16 GEAR-CLUTCH 29 1
1-17 PMO-ACTUATOR REGI SENSOR 1
1-18 ROLLER-EXIT 1
1-19 GUIDE-STACKER SUB 2
1-20 SHAFT-IDLE FEED 2
2 002N02446 MEA-ADF UPPER 1
2-1 COVER-M-ADF UPPER 1
2-2 500N00107 MEA UNIT-HOLDER ADF 1
2-2-1 HOLDER-M-ADF 1
2-2-2 019N00842 SHEET-ADF HOLDER 1
2-2-3 019N00566 ADF RUBBER 1
2-2-4 019N00843 SPRING ETC-PAD 1
3 002N02447 MEA-COVER OPEN 1
3-1 COVER-M-ADF OPEN 1
3-2 130N01414 MEA UNIT PICKUP ADF 1
3-2-1 022N02190 MEC-ADF ROLLER ASSEMBLY 1
3-2-2 013N13842 PMO-BUSH 1
3-2-3 022N02191 MEC-PICK UP ROLLER ASSEMBLY 1
3-3 038N00462 PMO-GUIDE PAPER 1
