Appendix D: DRP Address Map of the GTP Transceiver
0064 15:0 R/W TXPH_CFG 15:0 0-65535 0-65535
0065 12:8 R/W TXPH_MONITOR_SEL 4:0 0-31 0-31
0066 15:0 R/W RX_BIAS_CFG 15:0 0-65535 0-65535
0068 3 R/W RXOOB_CLK_CFG 0
PMA 0
FABRIC 1
0068 1 R/W TX_CLKMUX_EN 0 0-1 0-1
0068 0 R/W RX_CLKMUX_EN 0 0-1 0-1
0069 14:0 R/W TERM_RCAL_CFG 14:0 0-32767 0-32767
006A 15:13 R/W TERM_RCAL_OVRD 2:0 0-7 0-7
006A 4:0 R/W TX_CLK25_DIV 4:0
10
21
32
43
54
65
76
87
98
10 9
11 10
12 11
13 12
14 13
15 14
16 15
17 16
18 17
19 18
20 19
21 20
22 21
23 22
