Xilinx Virtex UltraScale+ FPGAs User Manual

Table 44: TX Programmable Divider Attribute (cont'd)
Attribute Type Description
TX_PROGDIV_FBKDIV [11:6] This attribute is the main TX programmable divider selector.
When the following settings are set:
TX_PROGDIV_SEL_DIV66 = 1’b1
TX_PROGDIV_PDBV_DIV5 = 1’b0
TX_PROGDIV_SEL_FULLRATE = 1’b1 (or 1’b0)
Valid TX programmable divider ratios are:
6'b011000: 4 (8)
6'b111000: 5 (10)
6'b000000: 8 (16)
6'b100000: 10 (20)
6'b000001: 12 (24)
6'b100001: 15 (30)
6'b000010: 16 (32)
6'b100010: 20 (40)
6'b000101: 24 (48)
6'b100011: 25 (50)
6'b100101: 30 (60)
6'b000110: 32 (64)
6'b100110: 40 (80)
6'b001101: 48 (96)
6'b100111: 50 (100)
6'b101101: 60 (120)
6'b001110: 64 (128)
6'b001111: 80 (160)
6'b101111: 100 (200)
When the following settings are set:
TX_PROGDIV_SEL_DIV66 = 1’b0
TX_PROGDIV_PDBV_DIV5 = 1’b1
TX_PROGDIV_SEL_FULLRATE = 1’b1 (or 1’b0)
Valid TX programmable divider ratios are:
6'b011000: 16.5 (33)
6'b000000: 33 (66)
6'b000010: 66 (132)
TX_PROGDIV_SEL_DIV66 [3] This attribute is used during the TX programmable divider
ratio selection.
• The attribute must be set to 1’b1 when the desired
divider value is either 16.5, 33, 66, or 132.
• For all other divider values, this should be set to 1’b0.
Chapter 3: Transmitter
UG581 (v1.0) January 4, 2019 www.xilinx.com
Virtex UltraScale+ GTM Transceivers 76
Send Feedback
