Xinje VH6 Series User Manual

162
Set the virtual X1 terminal status to be valid (A1-06=xxx1); Set the command source to terminal control
(P0-02=1);
Set the start protection to "unprotected" (P4-05=0);
After the inverter power on initialization is completed, it is detected that virtual X1 is effective, and the terminal
is forward running, which is equivalent to the frequency converter receiving a terminal forward running
command, and the inverter will start to run forward.
Parameter
Name
Range
A1-07
Function selection of AI1 terminal as
X terminal
Same to the function settings of X terminal
A1-08
Function selection of AI2 terminal as
X terminal
A1-10
Selection of effective mode when AI
is used as X terminal
Ones bit: AI1
0: High level valid
1: Low level valid
Tens bit: AI2
This group of function codes is used to use AI as X. When AI is used as X, if AI input voltage is greater than 7V,
AI terminal status is high level. If AI input voltage is lower than 3V, AI terminal status is low level. There is
hysteresis between 3V and 7V.
A1-10 is used to determine whether the AI high level is valid or the AI low level is valid when AI is X.
Parameter
Name
Range
A1-11
Virtual Y1 output function selection
0: Connect with physical Xx inside
1~42: same to physical Y output
A1-12
Virtual Y2 output function selection
A1-13
Virtual Y3 output function selection
A1-14
Virtual Y4 output function selection
A1-15
Virtual Y5 output function selection
A1-16
Virtual Y1 output delay time
0.0s~3600.0s
A1-17
Virtual Y2 output delay time
0.0s~3600.0s
A1-18
Virtual Y3 output delay time
0.0s~3600.0s
A1-19
Virtual Y4 output delay time
0.0s~3600.0s
A1-20
Virtual Y5 output delay time
0.0s~3600.0s
A1-21
Virtual Y terminal effective state
selection
Ones bit: Virtual Y1
0: Positive logic
1: Negative logic
Tens bit: virtual Y2
Hundreds bit: virtual Y3
Thousands bit: virtual Y4
Ten thousands bit: virtual Y5
Virtual digital output function is similar to Y output function of control board. It can be used to cooperate with
virtual digital input X to realize some simple logic control.
When the output function of virtual Y is selected as 0, the output states of virtual Y1 ~ Y5 are determined by the
input states of physical X1 ~ X5 on the control board. At this time, virtual Y corresponds to physical X.
When the virtual Y output function is not 0, the function setting and use method of virtual YI are the same as
those of P3 group Y output. Please refer to the description of P3 group Y output.
