Xinje VH6 Series User Manual

7
1-2. Specification
1-2-1. Technical specification
Model VH6-4_ _ _-B
3.7G/5.5P
5.5G/7.5P
7.5G/11P
11G/15P
15G/18P
18G/22P
22G/30P
Adaptive motor (KW)
G type
3.7
5.5
7.5
11.0
15.0
18.5
22.0
P type
5.5
7.5
11.0
15.0
18.5
22.0
30.0
Input rated current (A)
11
14.6
20.5
26.0
35.0
38.5
46.5
Power supply capacity (KVA)
5.9
8.9
11.0
17.0
21.0
24.0
30.0
Output rated current (A)
G type
9
13.0
17.0
25.0
32.0
37.0
45.0
P type
13.0
17.0
25.0
32.0
37.0
45.0
60.0
Model VH6-4_ _ _-B
30G/37P
37G/45P
45G/55P
55G/75P
75G/90P
90G/110P
110G/132P
Adaptive motor (KW)
G type
30.0
37.0
45.0
55.0
75.0
90.0
110.0
P type
37.0
45.0
55.0
75.0
90.0
110.0
132.0
Input rated current (A)
62.0
69.0
89.0
106.0
139.0
164.0
196.0
Power supply capacity (KVA)
40.0
63.0
81.0
97.0
127.0
150.0
179.0
Output rated current (A)
G type
60.0
75.0
90.0
110.0
152.0
176.0
210.0
P type
75.0
90.0
110.0
152.0
176.0
210.0
253.0
1-2-2. General specification
Item
Specification
Input
Rated voltage,
frequency
Three phase 380V: Three phase 380V, 50Hz/60Hz
Allowable voltage
fluctuation range
-15%~+15%, voltage unbalance rate: <3%
Output
Voltage
0~input voltage
Frequency
0~600Hz
Control
Control motor type
Asynchronous motor, permanent magnet synchronous motor, variable
frequency motor
Control performance
Vector control with speed
sensor (FVC)
Vector control without
speed sensor (SVC)
V/F control
(VVF)
Speed accuracy
±0.2%
±0.5%
±1%
Speed fluctuation
±0.2%
±0.3%
±0.5%
Speed range
1: 2000
1: 100
1: 50
Startup torque
0Hz: 180%
0.5Hz: 150%
1.0Hz: 150%
Torque accuracy
±5% of rated torque
±10% of rated torque
//
Torque response
≤10ms
≤20ms
//
Overload ability
G type: 150% of rated current: 60s
P type: 110% of rated current: 60s
Frequency accuracy
Low frequency operation mode: 0.01Hz
High frequency operation mode: 0.1Hz
Frequency resolution
Low frequency operation mode: digital setting--0.01Hz,
Analog setting –max frequency×0.1%
High frequency operation mode: digital setting--0.1Hz,
Analog setting-- max frequency ×0.1%
Control
Digital input channel
Up to 7 channels of digital input X.
