Xinje VH6 Series User Manual

8
Item
Specification
terminal
input
Card A has 4 channels (X1-X4) as standard. Card B can expand 3 channels
(X5-X7). (support 3KHz pulse input normally)
The X4 terminal can support the maximum 50 KHz high-speed pulse input.
Analog input channel
Up to three channels of analog input AI are supported.
Card A is equipped with two channels (AI1, AI2) as standard.
Card B can expand one channel (AI3).
AI1 and AI2 support 0 ~ 10V or 0 ~ 20mA input, AI3 supports -10V ~ 10V
input and can be used as PT100 input.
Control
terminal
output
Digital output channel
Up to 4 channels of digital output Y.
Card A is equipped with 1 channel (Y1) + 1 channel (TA1TB1TC1) as
standard.
Card B can expand 1 channel (Y2) + 1 channel (TA2TB2TC2).
Y2 terminal can support the maximum 50 kHz high-speed pulse output.
Analog output
channel
Up to two channels of analog output AO are supported.
Card A is equipped with 1 channel (AO1) .
Card B can expand 1 channel(AO2) .
AO1 and AO2 support 0 ~ 10V or 0 ~ 20mA.
Function
Startup command
setting
Communication setting (Modbus, CANopen, EtherCAT), operate panel
setting, terminal setting
Frequency setting
mode
Communication setting (Modbus, CANopen, EtherCAT), operate panel
setting, terminal setting, analog AI setting, multi-speed setting, simple PLC
setting, PID setting, main and auxiliary setting
Typical function
Frequency main and auxiliary operation, reverse inhibition, torque boost,
nine kinds of V/F curve settings, five segments of AI curve settings,
acceleration and deceleration curve settings, terminal delay and filtering,
terminal multi-function input and output, DC braking, energy consumption
braking, inching operation, 16 segments of speed, built-in two channels of
PID, speed tracking restart, carrier modulation, fault recording, fault self
reset, pre-excitation start, 30 groups of user defined parameters
Important function
Carrier modulation, torque control, motor auto-tuning, current limiting
control, over-voltage control, under voltage control, speed tracking, droop
control, vibration suppression, over-voltage and over-current stall control,
automatic voltage regulation (AVR), automatic energy-saving operation, etc
Protection function
Power on motor short-circuit detection, input and output phase loss
protection, over-current protection, over-voltage protection, under voltage
protection, overheat protection, overload protection, under load protection,
over-current and voltage stall protection, relay closing protection, terminal
protection, instantaneous power failure non stop, etc
Energy consumption
braking
380V level driver: action voltage of brake unit: 650~750V
3.7KW ~ 110KW power level is equipped with built-in braking unit as
standard, which only needs to connect braking resistor between P+ and PB
DC reactor
18.5KW and above are built-in DC reactors
Common DC bus
When the frequency converter decelerates, it shares the regenerative
energy, improves the braking ability, achieves the purpose of energy saving
and saves the additional space and cost required by the resistance.
