Group U0: Monitor parameters
Group U0: monitor parameters
Parameter
Name
Min unit
Modbus address
Display range
U0-00
Operation frequency (Hz)
0.01Hz
7000H
0.00~600.00Hz
U0-01
Setting frequency (Hz)
0.01Hz
7001H
0.00~600.00Hz
U0-02
Bus voltage (V)
0.1V
7002H
0.0~1024.0
U0-03
Output current (A)
0.01A
7003H
0.0~655.35A
U0-04
Output voltage (V)
1V
7004H
0V~1140V
U0-05
Output torque (%) Percentage output
value of motor rated torque
0.1%
7005H
-200.0%~200.0%
U0-06
Output power (kW)
0.1kW
7006H
0~32767
U0-07
X input state
1
7007H
0x0000~0x7FFF
U0-08
Y output state
1
7008H
0x0000~0x03FF
U0-09
AI1 voltage (V)/current(mA)
0.01V
7009H
0.00V ~10.57V
U0-10
AI2 voltage (V)/current (mA)
0.01V/0.01mA
700AH
0.00V ~10.57V
U0-11
AI3 voltage (V)/current(mA)
0.01V/0.01mA
700BH
0.00V ~10.57V
U0-12
PULSE input frequency
0.01KHz
700CH
0.00kHz ～
50.00KHz
U0-13
PULSE input frequency (Hz)
1
700DH
0 ～ 65535Hz
U0-14
PID setting
1
700EH
0 ～ 65535
U0-15
PID feedback
1
700FH
0 ～ 65535
U0-16
Load speed display
Depend on P8-22
7010H
0~65535
U0-17
Feedback speed (Hz)
Depend on P8-22
7011H
-600.00Hz~600.00
Hz
U0-18
Actual encoder feedback speed (Hz)
Depend on P8-22
7012H
-600.00Hz~600.00
Hz
U0-19
Line speed
1m/Min
7013H
0~65535
U0-20
PLC stage
1
7014H
0~15
U0-21
Count value
1
7015H
0~65535
U0-22
Length value
1
7016H
0~65535
U0-23
Main frequency A display
0.01Hz
7017H
0.01~600HZ
U0-24
Auxiliary frequency B display
0.01Hz
7018H
0.01~600HZ
U0-25
Communication setting
0.01%
7019H
-100.00%~100.00
%
U0-26
AI1 voltage/current before calibration
0.001V/0.001mA
701AH
0.000V~10.570V
U0-27
AI2 voltage/current before calibration
0.001V/0.01mA
701BH
0.000V~10.570V
U0-28
AI3 voltage/current before calibration
0.001V
701CH
0.000V~10.570V
U0-29
Remaining running time
0.1Min
701DH
0.0~6500.0min
U0-30
Present power on time
1Min
701EH
0~65000min
U0-31
Present operation time
0.1Min
701FH
0.0~6500.0min
U0-33
Present fault
1
7021H
0~56
U0-34
Fault information
1
7022H
-
U0-35
Target torque (%)
0.1%
7023H
-200.0%~200.0%
U0-36
Torque upper limit
0.01%
7024H
-200.00%~200.00
