Xinje VH6 Series User Manual

79
Group PE: user optional parameters
Parameter
Name
Setting range
Default
value
Modify
Modbus
address
PE-27
User optional parameters 27
Same to PE-00
U0-56
○
0E1BH
PE-28
User optional parameters 28
Same to PE-00
P0-00
○
0E1CH
PE-29
User optional parameters 29
Same to PE-00
P0-00
○
0E1DH
PE-30
User optional parameters 30
Same to PE-00
P0-00
○
0E1EH
PE-31
User optional parameters 31
Same to PE-00
P0-00
○
0E1FH
Group PF: Torque control(Firmware versions below 3720)
Group PF: Torque control
Parameter
Name
Setting range
Default value
Modify
Modbus
address
PF-00
Torque control
0: Speed control
1: Torque control
0
×
0F00H
PF-01
Upper limit source of driver
torque
0: Digital setting
1: AI1
2: AI2
3: AI3
4: PULSE
5: Communication setting
6: min(AI1, AI2)
7: max(AI1, AI2)
(the full scale of option 1~7 correspond
to PF-02 digital setting)
0
×
0F01H
PF-02
Driver torque upper limit
-200.0%~200.0%
150.0%
○
0F02H
PF-03
Torque control forward
direction max frequency
0.00Hz~max output frequency
50.00Hz
○
0F03H
PF-04
Torque control reverse
direction max frequency
0.00Hz~ max output frequency
50.00Hz
○
0F04H
PF-05
Torque acceleration time
0.00s~650.00s
0.00s
○
0F05H
PF-06
Torque deceleration time
0.00s~650.00s
0.00s
○
0F06H
Group PF: Torque control(Firmware versions 3720 and above)
Group PF: torque control
Parameter
Name
Setting range
Default value
Modify
Modbus
address
PF-00
Torque control
0: Speed control
1: Torque control
0
×
0F00H
PF-01
Upper limit source of
driver torque
0: Digital setting
1: AI1
2: AI2
3: AI3
4: PULSE
5: communication setting
0
×
0F01H
