Xinje VH6 Series User Manual

71
0：115200BPS
1：208300BPS
2：256000BPS
3：512000BPS
P9-03
MODBUS data format
0: No parity (8-N-2)
1: Even parity (8-E-1)
2: Odd parity (8-O-1)
3: No parity (8-N-1)
(Modbus valid)
1
○
0903H
P9-04
Communication timeout
0.0: Invalid
0.1~60.0s
0.0
○
0904H
P9-05
MODBUS response delay
0~20ms (Modbus valid)
2
○
0905H
P9-06
Extension card
communication
interruption detection
0.0~60.0s
0.0s
○
0906H
Group PA: Process control closed-loop parameters
Group PA: Process control closed-loop parameters
Parameter
Name
Setting range
Default
value
Modify
Modbus
address
PA-01
Setting channel selection
0: PA-05 setting
1: AI1
2: AI2
3: AI3
4: PULSE pulse setting (X4)
5: Communication setting
6: Multi-segment command setting
0
○
0A01H
PA-02
Feedback channel selection
0: AI1
1: AI2
2: AI3
3: AI1-AI2
4: AI1+AI2
5: PULSE pulse setting (X4)
6: Communication setting
0
○
0A02H
PA-03
PID feedback filter time
0.00s~30.00s
0.00s
○
0A03H
PA-04
PID output filter time
0.00s~30.00s
0.00s
○
0A04H
PA-05
PID value setting
0.0%~100.0%
50.0%
○
0A05H
PA-06
PID setting change time
0.00s~300.00s
0.00s
○
0A06H
PA-07
PID reverse cut-off frequency
0.00Hz~ Max output frequency
0.00Hz
○
0A07H
PA-08
PID deviation limit
0.0%~100.0%
0.0%
○
0A08H
PA-09
PID differential limit
0.00%~100.00%
0.10%
○
0A09H
PA-10
Proportional gain P
0.0~100.0
20.0
○
0A0AH
PA-11
Integral time I
0.01s~10.00s
2.00s
○
0A0BH
PA-12
Differential time D
0.000s~10.000s
0.000s
○
0A0CH
PA-13
PID parameter switching
0: Do not switch
0
○
0A0DH
