Xinje VH6 Series User Manual

80
Group PF: torque control
Parameter
Name
Setting range
Default value
Modify
Modbus
address
6: min(AI1, AI2)
7: max(AI1, AI2)
(the full scale of option 1~7 correspond to
PF-02 digital setting)
PF-02
Driver torque upper limit
-200.0%~200.0%
150.0%
○
0F02H
PF-03
Torque control forward
maximum frequency
source
0: Digital setting
1: AI1
2: AI2
3: AI3
4: PULSE
5: Communication setting
6: min(AI1, AI2)
7: max(AI1, AI2)
(the full scale of option 0~7 correspond to
P0-13 digital setting)
0
○
0F03H
PF-04
Torque control forward
maximum frequency
0.00Hz~max output frequency
50.00Hz
○
0F04H
PF-05
Torque control reverse
maximum frequency
source
0: Digital setting
1: AI1
2: AI2
3: AI3
4: PULSE
5: Communication setting
6: min(AI1, AI2)
7: max(AI1, AI2)
(the full scale of option 0~7 correspond to
P0-13 digital setting)
0
○
0F05H
PF-06
Torque control reverse
maximum frequency
0.00Hz~max output frequency
50.00Hz
○
0F06H
PF-07
Torque acceleration time
0.00s～650.00s
0.00s
○
0F07H
PF-08
Torque deceleration time
0.00s～650.00s
0.00s
○
0F08H
Group A0: Textile
Group A0: textile
Parameter
Name
Setting range
Default value
Modify
Modbus
address
A0-00
Setting length
0m~65535m
1000m
○
A000H
A0-01
Actual length
0m~65535m
0m
○
A001H
A0-02
Pulse number per meter
0.1~6553.5
100.0
○
A002H
A0-03
Setting count value
1~65535
1000
○
A003H
A0-04
Specified count value
1~65535
1000
○
A004H
A0-05
Swing frequency setting
mode
0: Relative to center frequency
1: Relative to the maximum
frequency
0
○
A005H
A0-06
Swing frequency range
0.0%~100.0%
0.0%
○
A006H
A0-07
Jump frequency amplitude
0.0%~50.0%
0.0%
○
A007H
A0-08
Swing frequency period
0.1s~3600.0s
10.0s
○
A008H
A0-09
Triangular wave rise time of
0.1%~100.0%
50.0%
○
A009H
