Xinje VH6 Series User Manual

88
Group U0: monitor parameters
Parameter
Name
Min unit
Modbus address
Display range
%
U0-37
Synchronous motor rotor position
1
7025H
0.1~360.0°
U0-38
Rotation position
1
7026H
0~4095
U0-39
ABZ position
1
7027H
0~65535
U0-40
Motor temperature
1°C
7028H
-
U0-41
Power factor angle
0.1°
7029H
-
U0-42
Setting frequency (%)
0.01%
702AH
-100.00%~100.00
%
U0-43
Operation frequency (%)
0.01%
702BH
-100.00%~100.00
%
U0-44
VF separate target voltage
1V
702CH
0V ~motor rated
voltage
U0-45
VF separate output voltage
1V
702DH
0V~motor rated
voltage
U0-46
Z signal counter
1
702EH
0~65535
U0-47
Motor serial number
0: motor 1
1: motor 2
702FH
-
U0-48
Check any memory address value
1
7030H
-
U0-53
Encoder feedback value 1 (supported
by 3720 and above )
0
7035H
0x0000~0xFFFF
U0-54
Encoder feedback value 2(supported
by 3720 and above )
0
7036H
0x0000~0xFFFF
U0-55
Encoder feedback value 3(supported
by 3720 and above )
0
7037H
0x0000~0xFFFF
U0-56
Encoder feedback value 4(supported
by 3720 and above )
0
7038H
0x0000~0xFFFF
U0-65
Cumulative operation time of
frequency converter (supported by
3720 and above versions)
1s
7041H
0~3600S
U0-66
Motor speed (supported by 3720 and
above versions)
1RPM
7042H
0~ rated speed
U0-67
Communication extension card type
-
7043H
-
U0-68
Communication extension version
-
7044H
-
U0-69
Communication expansion card VFD
state
Bit0:
0: Shutdown
1: In operation
7045H
0x0000~0xFFFF
Bit1: Operation
direction
0: Forward
1: Reverse
Bit2: Fault
0: No fault
1: Faulty
