Xinje VH6 Series User Manual

9
Item
Specification
Except that 75~110KW models need external pre charging circuit, other
power models can directly realize common DC bus.
Special
functions
Multi-bus
Main unit Modbus, extensible EtherCAT and CANopen
Multi-encoder
Differential input encoder, OC input encoder and resolver transformer
LCD panel
LCD display, parameter setting, status monitoring, parameter copy, fault
analysis and location, program download, mass storage of parameters
Non stop when
instantaneous power
failure
In case of instantaneous power failure, the load feedback energy
compensates for the decrease of voltage and keeps the inverter running for
a short time
Timing control
Timing control function: the time range is 0.1Min~6500.0Min
Multi-motor switching
Two sets of motor parameters can realize the switching control of two
motors
Motor overheat
protection
AI3 supports PT100 sensor function
Flexible and
diversified terminal
functions
Multi function terminal X has 51 types, Y has 42 types, AO has 19 kinds of
logic function selection, meet the general inverter control function
requirements
Communication
customization
parameters
It is convenient for users to read and write the inverter parameters
continuously
Software
Rich background monitoring function, convenient for field data collection
and debugging
Display
and
keyboard
Keyboard display
It can display the set frequency, output frequency, output voltage, output
current, input and output status and other parameters
Button locking
Realize the partial or total locking of keys to prevent false triggering
Parameter copy
Standard LED single display numeric keyboard, optional LCD English
display keyboard (parameter download)
Optional accessories
LCD keyboard, mainstream protocol communication card (EtherCAT,
CANopen), encoder PG card (incremental pulse, resolver)
Environ
ment
Using place
Indoor, free from direct sunlight, dust, corrosive gas, combustible gas, oil
mist, water vapor, dripping or salt, etc
Altitude
Below 1000 meters. (derating is required when the height is higher than
1000m, and the output current will be reduced by about 10% of the rated
current when the height is increased every 1000m.)
Ambient temperature
-10℃~+40℃ (When the ambient temperature is between 40℃ and 50℃,
please reduce the rating or enhance the heat dissipation)
Ambient humidity
Less than 95%RH, no condensation
Vibration
Less than 5.9 m/s² (0.6G)
Storage temperature
-40℃~+70℃
Protection level
IP20
Cooling mode
Forced air cooling
Installation mode
Wall mounted and embedded
