Xinje VH6 Series User Manual

69
Group P8: Keyboard and display
Parameter
Name
Setting range
Default
value
Modify
Modbus
address
Bit2: Bus voltage
Bit3: Output current
Bit4: Output voltage
Bit5: Output torque
Bit6: Output power
Bit7: X input status
Bit8: Y output status
Bit9: AI1 voltage
Bit10: AI2 voltage
Bit11: AI3 voltage
Bit12: PULSE input pulse frequency, the
unit is 0.01KHz
Bit13: PULSE input pulse frequency, the
unit is 1Hz
Bit14: PID setting
Bit15: PID feedback
Bit16: Load speed display
Bit17: Feedback speed, the unit is 0.1Hz
Bit18: Actual feedback speed
Bit19: Line speed
Bit20: PLC stage
Bit21: Counting value
Bit22: Length value
Bit23: Main frequency A display
Bit24: Auxiliary frequency B display
Bit25: Communication setting value
Bit26: Voltage before AI1 correction
Bit27: Voltage before AI2 correction
Bit28: Voltage before AI3 correction
Bit29: Remaining running time
Bit30: Current power on time
Bit31: Current running time
P8-08
LED operation display
parameter 2 (High bit)
0000
○
0808H
P8-09
LED stop display
parameters
The bit meaning
Bit0: The set frequency
Bit1: Bus voltage
Bit2: X input status
Bit3: Y output status
Bit4: AI1 voltage
Bit5: AI2 voltage
Bit6: AI3 voltage
Bit7: PULSE input pulse frequency
Bit8: PID setting
Bit9: Load speed display
0033
○
0809H
