Control Surface Operation with the Pro Tools Remote Layer 231
DM2000 Version 2—Owner’s Manual
SELECTED CHANNEL Section
■ ROUTING
[1] button
Selects the previous track to be controlled by the Joystick.
[2] button
Selects the next track to be controlled by the Joystick.
[3] button
Functions the same as the [OPTION] key on a computer keyboard.
[4] button
Switches between L and R of the selected track. The [4] button indicator lights up when the
R channel is selected.
[5] button
Selects Main, or Send (in this order) for the selected track.
[6] button
Switches the mode of the knob controls for the panner. The [6] button indicator lights up
or turns off.
[7] button
Selects Send, or Main (in this order) for the selected track.
[8] button
Mutes or unmutes the selected track. The [8] button indicator lights up while the track is
muted.
[DIRECT] button
Functions the same as the [SHIFT] key on the computer keyboard.
ROUTING
12
34
56
78
STEREOFOLLOW PAN DIRECT
DISPLAY
