344 Appendix B: Specifications
DM2000—Owner’s Manual
MATRIX 1L–4R
Comp-type
4
On/off
Pre EQ/pre fader/post fader
Attenuator –96.0 to +12.0 dB (0.1 dB step)
EQ
4-band PEQ
5
On/off
On/off —
Fader 100 mm motorized
Balance 127 positions (Left=1–63, Center, Right=1–63)
Delay 0–43400 samples
Metering
Displayed on LCD
Peak hold on/off
SURROUND MONITOR
Mute On/off
Solo On/off
Source BUS1–8, SLOT 1–6
Monitor to C-R On/off
Oscillator Pink noise/500–2 kHz/1 kHz
Monitor matrix
6.1→6.1, 6.1→5.1, 6.1→3-1, 6.1→ST, 5.1→5.1, 5.1→3-1, 5.1→ST,
3.1→3.1, 3.1→ST
Bass
management
5 presets
Monitor
alignment
ATT (–12.0 dB to 12 dB 0.1 dB step), Delay (0–30.0 msec, 0.01 msec
step)
INTERNAL EFFECTS
(EFFECT 1–8)
Bypass On/off
In/out
8-in, 8-out (EFFECT1–2): depends on effects type
2-in, 2-out (EFFECT3–8): depends on effects type
Effect-in from AUX1–12/INSERT OUT/effect-out
Effect-out to Input patch/effect-in
GRAPHIC EQUALIZERS
(GEQ 1–6)
On/off —
Band number 31
Limit ±15 dB, ±12 dB, ±6 dB, –24 dB
Insert position BUS1–8/AUX1–12/STEREO L, R/MATRIX 1L–4R
Power Requirements
U.S./Canada 120 V, 60 Hz 300 W
Other 220–240 V, 50/60 Hz 300 W
Dimensions (H x D x W) 257 x 821 x 906 mm (10.1" x 32.3" x 35.7")
Net weight 43 kg (94.8 lbs)
Operating free-air temperature range 10–35°C (50–95°F)
Storage temperature range –20 to 60°C (–4 to 140°F)
Supplied Accessories
AC Cable
CD-ROM (Studio Manager)
Options
Digital interface card (MY16, MY8, MY4 series)
PEAK METER BRIDGE: MB2000
SIDE PANEL: SP2000
1. Total harmonic distortion is measured with a 6 dB/octave filter @ 80 kHz.
2. Hum & Noise are measured with a 6 dB/octave filter @ 12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave
attenuation.
3. See “Gate Parameters” on page 345.
4. See “Comp Parameters” on page 345.
5. See “EQ Parameters” on page 345.
