7-15
1
2
3
4
5
6
7
8
9
10
SPECIFICATIONS
WIRE ROUTING DIAGRAM
Color code
1. Plastic locking tie 5. Oil warning unit lead
2. Wire harness protector 6. Engine switch
3. TCI unit lead 7. Oil warning unit
4. Clamp
A. As an indication of the tightening position of the plastic locking tie, the terminals are collectively set to
the center of the wire harness protector so as to be bundled.
B. Plastic locking tie should be within this range.
C. Clamp the terminals so as not to touch the crankcase.
D. Pass the lead through the hole in the crankcase.
B Black Y Yellow
Gy Gray B/W Black/White
To Next Page
