SPECIFICATIONS
WIRE ROUTING DIAGRAM
Color code
1. High tension cord 4. Oil warning unit lead
2. Flywheel 5. TCI unit
3. Oil warning unit
A. Make sure that the high tension cord is not pinched when installing the flywheel cover.
B. Adjust the TCI unit air gap between 0.4–0.6 mm (0.0157–0.0236 in) on both sides.
C. Contact between the protector and the edge is permitted, but contact between the wire lead and the
edge is not permitted.
B/W Black/White
