En 130
SETUP
Setting various functions (Setup menu)
Specifying menu display
Display Set
Specify front panel display brightness and TV screen wall paper.
Front Panel Display
Specify front panel display brightness and message scroll pattern.
Wall Paper
Specify the wall paper displayed on the TV screen when no video
signal is input. Select one that you prefer.
Setting TRIGGER OUT functions
Trigger Output1
Trigger Output2
Synchronizes TRIGGER OUT 1 or 2 jack function with the power
status of each zone or input switching.
Trigger Mode
Specify timing of electronic signal transmission to the TRIGGER
OUT 1 or 2 jack.
Target Zone
Specify the zone with which TRIGGER OUT 1 or 2 jack function
is synchronized.
Dimmer Adjustable range: -4 - 0
Reduce brightness of the front panel display. As the
value is lowered, the panel display darkens.
Scroll Selects the manner in which display scrolls when the
total number of characters exceeds the display area on
the front panel display.
Select “Continue” for continuous scrolling of all
characters.
Select “Once” to scroll through all characters once
and then halt scrolling for display of only the first 14
characters.
Picture 1-3 Displays an image on the TV screen when there is no
video signal.
Gray Displays a gray background on the TV screen when
there is no video signal.
Power (Default) TRIGGER OUT 1 or 2 jack function is synchronized
with the power status of the zone specified with
“Target Zone.
Source TRIGGER OUT 1 or 2 jack function is synchronized
with input switching in the zone specified with
“Target Zone.
Electronic signal is transmitted according to the
“Target Source” setting.
Manual Select this to manually switch the output level for
electronic signal transmission with “Manual.
Main When “Trigger Mode” is set to “Power,” electronic
signal transmission is synchronized with the power
status of the main zone.
When “Trigger Mode” is set to “Source,” electronic
signal transmission is synchronized with input
switching in the main zone.
Zone2 When “Trigger Mode” is set to “Power,” electronic
signal transmission is synchronized with the power
status of Zone2.
When “Trigger Mode” is set to “Source,” electronic
signal transmission is synchronized with input
switching in Zone2.
Zone3 When “Trigger Mode” is set to “Power,” electronic
signal transmission is synchronized with the power
status of Zone3.
When “Trigger Mode” is set to “Source,” electronic
signal transmission is synchronized with input
switching in Zone3.
Zone4 When “Trigger Mode” is set to “Power,” electronic
signal transmission is synchronized with the power
status of Zone4.
When “Trigger Mode” is set to “Source,” electronic
signal transmission is synchronized with input
switching in Zone4.
All (Default) When “Trigger Mode” is set to “Power,” electronic
signal transmission is synchronized with the power
status of the main zone or Zone2, Zone3 or Zone4.
When “Trigger Mode” is set to “Source,” electronic
signal transmission is synchronized with input
switching in the main zone or Zone2, Zone3 or Zone4.
