En 126
SETUP
Setting various functions (Setup menu)
Setting this unit’s multi-zone function
Multi Zone setup items
■
Adjusting Zone2 or Zone3 volume
Zone2 Set
Zone3 Set
Volume
Selects whether or not volume level adjustment of Zone2 or Zone3
speakers is enabled.
Max Volume
Specify the maximum volume level in Zone2 or Zone3 so that
sound is not too loud.
Initial Volume
Specify the initial volume level in Zone2 or Zone3 when this unit is
turned on.
Mono
Switches between stereo and monaural modes for Zone2 or Zone3
audio signal.
■
Selecting the zone for optical output
signal
Digital Out Assign
Selects main zone or Zone4 to which the optical audio signals are
output from AV OUT/ZONE4 jacks.
Zone2 Set Sets the Zone2 functions.
Zone3 Set Sets the Zone3 functions.
Digital Out Assign Selects a zone to which the digital audio signals are
output from AV OUT/ZONE4 jacks.
Monitor Out Assign Displays the menus of Zone2, Zone3 or Zone4 on the
TV monitor.
Party Mode Set Enable or disable the party mode function.
Zone Scene Rename Changes the scene names of Zone.
Zone Rename Changes the name of Zone2, Zone3 or Zone4.
Fixed Disables volume level adjustment of Zone2 or Zone3
speakers
.
Variable (Default) Enables volume level adjustment of Zone2 or Zone3
speakers
.
When setting the Power Amp Assign function, “Volume” is
automatically set to “Variable.” Refer “Speaker layout”
(☞
p. 16) for details on the Power Amp Assign function.
Adjustable range -30.0 dB to +16.5 dB (maximum volume)
Default setting +16.5 dB
Adjustment
increments
5.0 dB
Adjustable range Off, Mute, -80.0 dB to +16.5 dB
Default setting Off
Adjustment
increments
0.5 dB
Off (Default) Does not convert Zone2 or Zone3 audio signal to
monaural sound.
On Converts Zone2 or Zone3 audio signal to monaural
sound.
Main Outputs the optical signals to the main zone.
Zone4 Outputs the optical signals to Zone4.
To Next Page
