APPENDIX
En 170
■ Input
• Analog Audio
RCA ...............................................................................................10
AV1-4, AUDIO1-4, PHONO, VIDEO AUX
MULTI CH INPUT...................................................................... 8ch
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, SUBWOOFER
• Digital Audio
Optical ...................................... 4 (AV3-4, AUDIO1, VIDEO AUX)
Coaxial.............................................................. 3 (AV1-2, AUDIO2)
• Analog Video
Composite..................................................5 (AV1-4, VIDEO AUX)
S-video.......................................................5 (AV1-4, VIDEO AUX)
Component ........................................................................4 (AV1-4)
•Other
DOCK.............................1 (Audio L/R, Composite Video, S-video)
■ Output
• Analog Audio
SPEAKERS .................................................. 11ch (7ch + Extra 4ch)
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK/BI-AMP L/R,
EXTRA SP1 (ZONE2/ZONE3/F.PRESENCE L/R),
EXTRA SP2 (ZONE2/ZONE3/R.PRESENCE L/R)
PRE OUT..................................................................................... 9ch
FRONT/F.PRESENCE L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, R.PRESENCE L/R*
*: Barter to Zone3
SUBWOOFER (Stereo, Front & Rear 2ch)
AV OUT...........................................................................................1
ZONE2 OUT ...................................................................................1
ZONE3/R.PRESENCE OUT .......................................................... 1
• Digital Audio
Optical ....................................................1 (AV OUT/ZONE4 OUT)
• Analog Video
MONITOR OUT/ZONE OUT
Composite .....................................................................................1
S-video .......................................................................................... 1
Component....................................................................................1
AV OUT
Composite..................................................................................... 1
S-video.......................................................................................... 1
■ HDMI
• Input............................................................. 8 (AV1-7, VIDEO AUX)
• Output .........................................................................2 (HDMI OUT)
• HDMI Specification
Deep Color 30/36 bit, “x.v.Color,” Auto Lips Sync, HD Audio,
ARC (Audio Return Channel), 3D
•Audio Format
Dolby Digital, DTS, DSD 6ch, Dolby Digital Plus, Dolby TrueHD,
DTS-HD, PCM 2ch-8ch
• Content Protection ..................................................HDCP compatible
■ Tuner
• Analog Tuner
FM/AM .......................................................................... 1 (TUNER)
• [U.S.A. model] HD Radio with iTunes Tagging............... 1 (TUNER)
• [U.S.A. model] Satellite Radio Ready
SIRIUS Radio.................................................................. 1 (SIRIUS)
■ Network
• USB (USB1.1 Full Speed) ................................................................. 1
Device Type..................................... USB Mass Storage Class, MTP
Audio Format ................ MP3, WMA, WAV, MPEG-4 AAC, FLAC
Max Audio Support fs................................................. 48 kHz/24 bit
Cover Art Format ........................................................... PNG, JPEG
• Ethernet (100Base-TX/10Base-TX) .................................................. 1
Internet Radio
Audio Format.............................................................. MP3, WMA
PC Server
Audio Format.............. MP3, WMA, WAV, MPEG-4 AAC, FLAC
Max Audio Support fs .............................................. 96 kHz/24 bit
Cover Art Format......................................................... PNG, JPEG
DLNA
Version ............................................... 1.5 (DMP & DMR support)
Audio Format ............. MP3, WMA, WAV, MPEG-4 AAC, FLAC
Max Audio Support fs...............................................96 kHz/24 bit
Cover Art Format .........................................................PNG, JPEG
[U.S.A. model] Internet Music Service
Rhapsody, Sirius Internet Radio
Network Control
Web Browse Control, MusicCAST2 Commander Support,
Yamaha Network Control Support (YNC), Receiver Manager
Support
■ Remote
• RS-232C .............................................................................................1
• REMOTE IN.......................................................................................2
• REMOTE OUT...................................................................................2
• TRIGGER OUT ...................................... 2 (12 V/total 100 mA max.)
■ Compatible Decoding Format
• Decoding Format
Dolby TrueHD, Dolby Digital Plus, Dolby Digital,
Dolby Digital EX, DTS-HD Master Audio,
DTS-HD High Resolution Audio, DTS Express, DTS,
DTS-ES Matrix 6.1, DTS-ES Discrete 6.1, DTS 96/24
• Post Decoding Format
Dolby Pro Logic, Dolby Pro Logic II Music,
Dolby Pro Logic II Movie, Dolby Pro Logic II Game,
Dolby Pro Logic IIx Music, Dolby Pro Logic IIx Movie,
Dolby Pro Logic IIx Game, DTS Neo:6 Music, DTS Neo:6 Cinema
■ Audio Section
• Minimum RMS Output Power (20 Hz to 20 kHz, 0.06 % THD, 8 Ω)
FRONT L/R .............................................................140 W + 140 W
CENTER.................................................................................140 W
SURROUND L/R ....................................................140 W + 140 W
SURROUND BACK L/R ....................................................... 140 W
• Dynamic Power (IHF)
FRONT L/R, 8/6/4/2 Ω ......................................175/220/295/415 W
Specifications
