PLAYBACK
Configuring settings specific to an individual input source (Option menu)
En 63
Option menu
The following items are provided for each input source. “✓” indicates the available menu for each input source. J1
AV1-4 AV5-7 V-AUX AUDIO1-4 PHONO MULTI CH USB PC
NET
RADIO
Rhapsody SIRIUS IR
DOCK
(iPod)
DOCK
(Bluetooth)
TUNER SIRIUS
Tone Control ✓✓✓✓✓ ✓✓✓✓✓✓ ✓ ✓✓
Adaptive DRC ✓✓✓✓✓ ✓✓✓✓✓✓ ✓ ✓✓
CINEMA DSP
3D Mode
✓✓✓✓✓ ✓✓✓✓✓✓ ✓ ✓✓
Dialogue
Lift J2
✓✓✓✓✓ ✓✓✓✓✓✓ ✓ ✓✓
Extended
Surround
✓✓✓✓J3
Volume Trim ✓✓✓✓✓✓✓✓✓✓✓✓ ✓ ✓✓
Video
Adjustment
✓✓✓J4 ✓ J4
Audio Select ✓✓✓J3 ✓ J3
Shuffle ✓✓ ✓ ✓J5
Repeat ✓✓ ✓ ✓J5
Connect ✓
Disconnect ✓
Pairing ✓
J
1 : When “Tone Control,” “Adaptive DRC,” “CINEMA DSP 3D Mode,”
“Dialogue Lift,” or “Extended Surround” is adjusted for an input source, the
same value is applied to other input sources and “ALL” is displayed on the
front panel display. When settings specific to a certain input source are
selected, the input source name is displayed on the front panel display. If the
name of the input source has been changed (☞
p. 103), the original name of the
input source is displayed.
J
2 : “Dialogue Lift” can be adjusted only when the presence speakers are available.
J
3 : This function is only available when “Coax/Opt” is assigned to this input
source from “Input Assignment” in the Setup menu. Refer to “Assigning
component input and output jacks” (☞
p. 129) for details.
J
4 : This function can be set only when “Component” is assigned to this input
source from “Input Assignment” in the Setup menu. Refer to “Assigning
component input and output jacks” (☞
p. 129) for details.
J
5 : Not available for Yamaha Wireless System for iPod.
