GENERAL CHASSIS
4-2
Removing the side cover
Order Job/Parts to remove Q’ty Remarks
1 Air filter case cover 1
Refer to “CLEANING THE AIR FILTER ELE-
MENT” on page 3-16.
2 Air scoop (left) 1
3 Air scoop (right) 1
4 Side cover (right) 1
5 Rear fender 1
5
4
1
3
2
1
7 N・m (0.7 kgf・m, 5.2 lb・ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
1.3 N・m (0.13 kgf・m, 0.95 lb・ft)
16 N・m (1.6 kgf・m, 12 lb・ft)
