ENGINE REMOVAL
5-10
Removing the engine
Order Job/Parts to remove Q’ty Remarks
8 Upper engine bracket (right) 1
9 Upper engine bracket (left) 1
10 Lower engine bracket (outside) 2
11 Lower engine bracket (inside) 2
12 Pivot shaft 1
13 Engine 1
7 N・m (0.7 kgf・m, 5.2 lb・ft) 34 N・m (3.4 kgf・m, 25 lb・ft)
85 N・m (8.5 kgf・m, 63 lb・ft)
75 N・m (7.5 kgf・m, 55 lb・ft)
34 N・m (3.4 kgf・m, 25 lb・ft)
53 N・m (5.3 kgf・m, 39 lb・ft)
55 N・m (5.5 kgf・m, 41 lb・ft)
26 N・m (2.6 kgf・m, 19 lb・ft)
34 N・m (3.4 kgf・m, 25 lb・ft)
45 N・m (4.5 kgf・m, 33 lb・ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
8
9
11
12
13
10
10
11
