CLUTCH
5-55
10.Install:
• Clutch spring
• Clutch spring bolt
TIP
Tighten the bolts in stages and in a crisscross
pattern.
11.Install:
• Gasket “1”
12.Install:
• Clutch cover
• Clutch cover bolt
TIP
Tighten the bolts in stages and in a crisscross
pattern.
Clutch spring bolt
10 N·m (1.0 kgf·m, 7.4 lb·ft)
Clutch cover bolt
10 N·m (1.0 kgf·m, 7.4 lb·ft)
a
a
b
b
T
R
.
.
New
1
T
R
.
.
