5.4 Noise Filter
5-15
Peripheral Devices
5
(4) Model: HF3200C-SZC-49EDE
Note: Also use a compact AC power supply block-type capacitor (X capacitor).
Model: LDA106M-AA (Soshin Electric Co., Ltd.)
 Compact AC Power Supply Block-type Capacitor (X Capacitor) Model: LDA106M-AA
380±2
400±5
90±2
120±5
6.5 dia.
260±5
(29)
(32) (32)
6.5
Nameplate
1
4
5
2
3
5
EMI FILTER
4
LOAD
SOSHIN ELECTRIC CO., LTD.
SOSHIN
5
6
3
2
LINE
1
LOT.No,
TYPE
RATING
HF3200C-SZC
500 VAC 200 A
50 / 60 Hz
TUV
..
25/85/21
50
CUS
1
Input terminal: M10
2
Case
4
Output terminal: M10
5
Earth terminal: M8
3
Nameplate
Unit: mm
Rated voltage and current
Example of Nameplate: HF3200C-SZC
Model name
Rated frequency
Lot No.
C3
C2
C1
(T)
(S)
(R)
40/100/21
(S)
(T)
(R)
C1,C2,C3=10μF±20%
LDA106M-AA
250V 㨪
1209
(R) Red
(S) White
(T) Black
3-UL1015 AWG18
(5)
106
94
82±2
43±2
270 min.
56±2
2-5.5 dia.
R
SE
࡮
࡮
㧾㨔㨑㨕㨚㨘㨍㨚㨐
㨀㨁㨂
Unit: mm
