YASKAWA CACR-JU series User Manual

5 Peripheral Devices
5.5.3 External Dimensions
5-18
5.5.3 External Dimensions
(1) Model: JUSP-JUBM050AA
2-6 Dia.
12 20
460
440 425
(8)
(15)
64.6
105 (23)
15
10 (10)30
50
Cooling Fan
Air Flow
Nameplate
Air Flow
Approx.Mass: 2.7 kg
Unit: mm
4-M5 Screw Holes
Base Mounting
Unit Rear View
<Mounting Hole Diagram> <Unit Mounted Diagram>
12
460
10 (305)
50
440
±
0.5(Mounting Pitch)
(Mounting Pitch)
30
±
0.5
