6.2.2 Thermal Design of Control Panel
Install the Σ-V-SD drivers, host controllers, and other units in a control panel.
Use a control panel with an enclosed structure that provides protection against corrosive gases, water, and oil.
Also, design the system so that the temperature rise in the control panel does not cause the temperature to
exceed the ambient operating temperature.
(1) Calorific Value
Power Regeneration Converter
SERVOPACK for One Axis
SERVOPACK for Two Axes
Model
Calorific Value at Continuous Rated Operation
Tot al ( W)
Loss of Control
Block (W)
Loss of Power Block (W)
Tot al Inside Duct
CACP-JU15A3 116.4 13.1 103.3 10.3 93.0
CACP-JU19A3 154.3 13.1 141.2 14.1 127.1
CACP-JU22A3 183.8 13.1 170.7 17.1 153.6
CACP-JU30A3 247.2 14.7 232.5 23.2 209.3
CACP-JU45A3B 394.7 14.7 380.0 38.0 342.0
CACP-JU15D3 66.8 13.1 53.7 5.4 48.4
CACP-JU19D3 90.5 13.1 77.4 7.7 69.7
CACP-JU22D3 104.8 13.1 91.7 9.1 82.6
Model
Calorific Value at Continuous Rated Operation
Tot al ( W)
Loss of Control
Block (W)
Loss of Power Block (W)
Tot al Inside Duct
CACR-JU028ACA 151.4 16.3 135.1 27.0 108.1
CACR-JU036ACA 178.3 16.3 162.0 32.4 129.6
CACR-JU065ACA 321.5 16.2 305.3 30.5 274.8
CACR-JU084ACA 421.9 18.9 403.0 40.3 362.7
CACR-JU102ACA 476.1 18.9 457.2 45.7 411.5
CACR-JU125ACA 611.8 25.9 585.9 58.6 527.3
CACR-JU196ACA 1319.7 27.1 1292.6 129.3 1163.3
CACR-JU014DCA 139.4 16.9 122.5 24.5 98.0
CACR-JU018DCA 165.9 16.9 149.0 29.8 119.2
CACR-JU033DCA 305.7 16.3 289.4 28.9 260.5
CACR-JU042DCA 365.8 18.9 346.9 34.7 312.2
CACR-JU051DCA 422.2 18.9 403.3 40.3 363.0
Model
Calorific Value at Continuous Rated Operation
Tot al ( W)
Loss of Control
Block (W)
Loss of Power Block (W)
Tot al Inside Duct
CACR-JUM23ACA 134.4 23.4 111.0 22.2 88.8
CACR-JUM24ACA 199.4 23.4 176.0 35.2 140.8
CACR-JUM25ACA 248.8 26.8 222.0 22.2 199.8
CACR-JUM23DCA 113.2 23.4 89.8 9.0 80.8
CACR-JUM24DCA 145.6 23.4 122.2 12.2 110.0
CACR-JUM25DCA 215.2 26.8 188.4 18.8 169.6
