YASKAWA CACR-JU series User Manual

5 Peripheral Devices
5.2.1 Specifications
5-4
5.2 AC Reactor
5.2.1 Specifications
∗ This AC reactor does not comply with UL standards. If an AC reactor that complies with UL standards is required,
contact your Yaskawa representative.
Power Regeneration
Converter Model
AC Reactor
Model
Rated
Voltage
(V)
Frequency
(Hz)
Rated
Current
(A)
Inductance
(mH)
Insula-
tion
Class
(class)
Watt
Data
Loss
(W)
Ambi-
ent
Te m p er -
ature
Storage
Te m p er -
ature
Ap-
prox.
Mass
(kg)
CACP-JU15A3 X008017 230 50/60 56 0.21 H 55
–10 to
55°C
–20 to
85°C
8
CACP-JU19A3 X008018 230 50/60 73 0.17 H 70
–10 to
55°C
–20 to
85°C
8
CACP-JU22A3 X008019 230 50/60 90 0.14 H 80
–10 to
55°C
–20 to
85°C
12
CACP-JU30A3 X008020 230 50/60 107 0.1 H 85
–10 to
55°C
–20 to
85°C
12
CACP-JU45A3B X008022 230 50/60 179 0.07 H 130
–10 to
55°C
–20 to
85°C
25
CACP-JU15D3
X008010
*
480 50/60 27 0.82 H 70
–10 to
55°C
–20 to
85°C
7.3
CACP-JU19D3 X008011 480 50/60 36 0.67 H 80
–10 to
55°C
–20 to
85°C
7.3
CACP-JU22D3 X008012 480 50/60 45 0.56 H 120
–10 to
55°C
–20 to
85°C
11.2
