(7) I/O Cable Specifications for SERVOPACKs for One Axis
∗ The soldered type is 10126-3000PE (Sumitomo 3M Ltd.).
(8) I/O Cable Specifications for SERVOPACKs for Two Axes
∗ The soldered type is 10150-3000PE (Sumitomo 3M Ltd.).
(9) Cable Specifications for Use with EtherCAT (CoE) Communications
(10) Cable Specifications for Use with an Analog Monitor
(11) Cable Specifications for Use with a Computer
Items length Specifications
Order No.
1 m JZSP-CSI02-1-E
2 m JZSP-CSI02-2-E
3 m JZSP-CSI02-3-E
Cable and
connector
Cable: SSRFPVV-SB AWG#28 × 13P, UL20276 VW-1SC
Shell: 10326-52A0-008 (Sumitomo 3M Ltd.)
Connector: 10126-6000EL (Crimping type, Sumitomo 3M Ltd.)
*
Remarks Used for input signals, such as P-OT and N-OT.
Items length Specifications
Order No.
1 m JZSP-CSI01-1-E
2 m JZSP-CSI01-2-E
3 m JZSP-CSI01-3-E
Cable and
connector
Cable: SSRFPVV-SB AWG#28 × 25P, UL20276 VW-1SC
Shell: 10350-52A0-008 (Sumitomo 3M Ltd.)
Connector: 10150-6000EL (Crimping type, Sumitomo 3M Ltd.)
*
Remarks Used for input signals, such as P-OT and N-OT.
Items Specifications
Cable Length 100 m max.
Cable and
connector
Cable: CAT5 STP 4pairs
Connector: RJ-45
Remarks
If you make your own cable, make sure that there is electrical continuity between
the cable shield and connector shell.
Recommended cable: ZB9020 (manufactured by Beckhoff Automation GmbH)
Items Specifications
Order No. JZSP-CA01-E
Cable length 1 m
Connectors
Cable: STYLE 1007 AWM E74037, AWG24 VW-1
Connector: DF11-4DS-2C
Remarks Used for analog output signals, such as speed reference and torque reference.
Items Specifications
Order No. JZSP-CVS06-02-E
Cable length 2.5 m
Connectors
Cable-end connector to SERVOPACK: USB Type miniB
Cable-end connector to computer: USB Type A
Remarks
Used to connect a SERVOPACK with a personal computer in which SigmaWin
for Σ-V-SD (MT) is installed.
