3.1 Spindle Motor
3-9
Specifications and External Dimensions for Motors
3
19C
High-speed winding High-speed winding
Low-speed winding Low-speed winding
22C
High-speed winding High-speed winding
Low-speed winding Low-speed winding
(cont’d)
Model
UAKBJ-
Output Characteristics Tor q ue Ch ar ac te ri st ic s
Motor speed (min
-1
)
Output (kW)
30ޓ10 second rating
60001500 3500
12.0
14.8
17.5
4800
18.5ޓ50㧑ED rating
15ޓContinuous rating
Motor speed (min
-1
)
Torque (N࡮m)
1500 3500
4800
6000
118
95.5
191ޓ10 second rating
50㧑ED rating
Continuous rating
Motor speed (min
-1
)
Output (kW)
15ޓContinuous rating
1500575
22.2ޓ10 second rating
18.5ޓ50㧑ED rating
Motor speed (min
-1
)
Torque (N࡮m)
575 1500
307
369ޓ10 second rating
50㧑ED rating
249ޓ
Continuous rating
Motor speed (min
-1
)
Output (kW)
37ޓ10 second rating
60001500 3500
14.8
17.6
21.5
4800
22ޓ50㧑ED rating
18.5ޓContinuous rating
Motor speed (min
-1
)
Torque (N࡮m)
1500 3500
4800
6000
140
118
236ޓ10 second rating
50㧑ED rating
Continuous rating
Motor speed (min
-1
)
Output (kW)
18.5ޓContinuous rating
1500575
26.4ޓ10 second rating
22ޓ50㧑ED rating
Motor speed (min
-1
)
Torque (N࡮m)
575 1500
365
439ޓ10 second rating
50㧑ED rating
307ޓ
Continuous
rating
