Installing Fuses on the Input Side
Install recommended UL-approved fuses at the main power input of the drive. Select fuses
according to Table 7.3.
Table 7.3 Recommended Input Fuse Selection
Drive Model
CIMR-Jo
Class T Fuses Class L Fuses
Model Fuse Ampere Rating Model Fuse Ampere Rating
200 V Class Single-Phase Drives
BA0001 A6T15 15 CR6L-20/UL 20
BA0002 A6T20 20 CR6L-30/UL 30
BA0003 A6T20 20 CR6L-50/UL 50
BA0006 A6T40 40 CR6L-75/UL 75
BA0010 A6T40 40 CR6L-100/UL 100
200 V Class Three-Phase Drives
2A0001 A6T10 10 CR6L-20/UL 20
2A0002 A6T10 10 CR6L-20/UL 20
2A0004 A6T15 15 CR6L-20/UL 20
2A0006 A6T20 20 CR6L-30/UL 30
2A0008 A6T25 25 CR6L-50/UL 50
2A0010 A6T25 25 CR6L-50/UL 50
2A0012 A6T30 30 CR6L-50/UL 50
2A0018 A6T40 40 CR6L-75/UL 75
2A0020 A6T40 40 CR6L-75/UL 75
400 V Class Three-Phase Drives
4A0001 A6T10 10 CR6L-20/UL 20
4A0002 A6T10 10 CR6L-20/UL 20
4A0004 A6T20 20 CR6L-50/UL 50
4A0005 A6T25 25 CR6L-50/UL 50
4A0007 A6T25 25 CR6L-50/UL 50
4A0009 A6T25 25 CR6L-50/UL 50
4A0011 A6T30 30 CR6L-50/UL 50
u
Installing a Motor Thermal Overload (oL) Relay on the Drive
Output
Motor thermal overload relays protect the motor by disconnecting power lines to the motor
due to a motor overload condition.
Install a motor thermal overload relay between the drive and motor:
• When operating multiple motors on a single AC drive.
• When using a power line bypass to operate the motor directly from the power line.
7.4 Installing Peripheral Devices
178
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
