H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
No. Name Description Range Def.
Mode
Addr.
Hex
Pg.
V/f
H1: Multi-Function Digital Input
H1 parameters to assign functions to the
multi-function digital input terminals. Unused terminals should be set to "F".
H1-01
Multi-Function Digital
Input Terminal S1
Function Selection
Assigns a function to the multi-function
digital inputs.
Refer to H1 Multi-Function Digital Input
Selections on page 206 for a description of
setting values.
1 to 67
40 O 438 —
H1-02
Multi-Function Digital
Input Terminal S2
Function Selection
41 O 439 —
H1-03
Multi-Function Digital
Input Terminal S3
Function Selection
0 to 67
24 O 400 —
H1-04
Multi-Function Digital
Input Terminal S4
Function Selection
14 O 401 —
H1-05
Multi-Function Digital
Input Terminal S5
Function Selection
3 (0)
<18>
O 402 —
<18> Parenthetical value is the default when parameter A1-03 = 3330 3-Wire Initialization.
H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description
Mode
V/f
0 3-Wire Sequence
Closed: Reverse rotation (only if the drive is set up for 3-Wire
sequence)
O
1 LOCAL/REMOTE Selection
Open: REMOTE, Reference 1 (b1-01/02)
Closed: LOCAL, LED operator is run and reference source
O
2 External Reference 1/2
Open: Run and frequency reference source 1 (b1-01/02)
Closed: MEMOBUS/Modbus Communication
O
3 Multi-Step Speed Reference 1
Used to select Multi-Step Speeds set in d1-01 to d1-08
O
4 Multi-Step Speed Reference 2 O
5 Multi-Step Speed Reference 3 O
6 Jog Reference Selection
Open: Selected speed reference
Closed: Jog Frequency reference (d1-17). Jog has priority over
all other reference sources.
O
7 Accel/Decel Time 1 Used to switch between Accel/Decel Time O
8 Baseblock Command (N.O.)
Open: Normal operation
Closed: No drive output
O
9 Baseblock Command (N.C.)
Open: No drive output
Closed: Normal operation
O
A Accel/Decel Ramp Hold
Closed: The drive pauses during acceleration or deceleration and
maintains the output frequency.
O
F Not used
Select this setting when not using the terminal or when using the
terminal in a pass-through mode.
O
B.2 Parameter Table
206
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
2/6/2008-14:44
