Parameters Available in the Setup Group
n
Setup Mode (STUP)
Parameters used for this drive are classified into A to U. To simplify the drive setup, frequently
used parameters are selected and input into Setup Mode.
1.
To set a parameter, the Setup Mode must be displayed first. Press the Up/Down key
until is displayed.
2.
Select the parameter and change the setting. Table 4.4
lists parameters available in
the Setup group. If the desired parameter cannot be set in the Setup mode, use the
Parameter Setting mode.
Note: This manual also explains other parameters not visible in the Setup Group (A1-06 = 0). Use the “Par” menu
in the Programming mode to access parameters not listed in the Setup Group.
Table 4.4 Setup Group Parameters
Parameter Name
b1-01 Frequency Reference Selection
b1-02 Run Command Selection
b1-03 Stop Method Selection
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C6-01 Duty Selection
C6-02 Carrier Frequency Selection
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
Parameter Name
d1-17 Jog Frequency Reference
E1-01 Input Voltage Reference
E1-04 Maximum Output Frequency
E1-05 Maximum Voltage
E1-06 Base Frequency
E1-09 Minimum Output Frequency
E2-01 Motor Rated Current
H4-02 Terminal FM Gain Setting
L1-01 Motor Protection Function Selection
L3-04
Stall Prevention Selection during
Deceleration
4.3 The Drive and Programming Modes
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
85
4
Start-Up Programming & Operation
