No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0001 2A0002 2A0004 2A0006 2A0008
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection − 96 (60H) 97 (61H) 98 (62H) 99 (63H) 100 (64H)
− Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1 1.1 1.5
L2-03
Momentary power loss
Baseblock time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.4
No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0010 2A0012 2A0018 2A0020
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection − 101 (65H) 102 (66H) 103 (67H) 104 (68H)
− Motor rated power kW 1.5 2.2 2.2 3.0 3.0 3.7 3.7 5.5
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01 Motor rated current A 6.20 8.50 8.50 11.40 11.40 14.00 14.00 19.60
E2-02 Motor rated slip Hz 2.60 2.90 2.90 2.70 2.70 2.73 2.73 1.50
E2-03 Motor no-load current A 2.80 3.00 3.00 3.70 3.70 4.50 4.50 5.10
E2-05
Motor line-to-line
resistance
Ω 1.997 1.601 1.601 1.034 1.034 0.771 0.771 0.399
L2-02
Momentary power loss ride-
through time
s 0.3 0.3 0.5 0.5 1 1 1 1
L2-03
Momentary power loss
Baseblock time
s 0.4 0.5 0.5 0.5 0.5 0.6 0.6 0.7
Table B.3 Three-Phase 400 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
−
Model CIMR-Jo
− 4A0001 4A0002 4A0004 4A0005
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection Hex 91 92 93 94
− Motor rated power kW 0.2 0.4 0.4 0.75 0.75 1.5 1.5 2.2
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01 Motor rated current A 0.60 1.00 1.00 1.60 1.60 3.10 3.10 4.20
E2-02 Motor rated slip Hz 2.50 2.90 2.90 2.60 2.60 2.50 2.50 3.00
E2-03 Motor no-load current A 0.40 0.60 0.60 0.80 0.80 1.40 1.40 1.50
E2-05
Motor line-to-line
resistance
Ω 83.94 38.198 38.198 22.459 22.459 10.1 10.1 6.495
L2-02
Momentary power loss ride-
through time
s 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
L2-03
Momentary power loss
Baseblock time
s 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
No. Description Unit Default Setting
−
Model CIMR-Jo
− 4A0007 4A0009 4A0011
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND
o2-04 Drive Model Selection − 95 96 97
− Motor rated power kW 2.2 3.0 3.0 3.7 4.0 5.5
C6-02 Carrier frequency − 3 7 3 7 3 7
B.3 Defaults Determined by Drive Capacity (o2-04) and ND/HD (C6-01)
220
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
2/6/2008-14:44
