YASKAWA CIMR-JA Series User Manual

No. Description Unit Default Setting
−
Model CIMR-Jo
− 4A0007 4A0009 4A0011
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND
o2-04 Drive Model Selection − 95 96 97
− Motor rated power kW 2.2 3.0 3.0 3.7 4.0 5.5
E2-01 Motor rated current A 4.20 5.70 5.70 7.00 7.00 9.80
E2-02 Motor rated slip Hz 3.00 2.70 2.70 2.70 2.70 1.50
E2-03 Motor no-load current A 1.50 1.90 1.90 2.30 2.30 2.60
E2-05 Motor line-to-line resistance Ω 6.495 4.360 4.360 3.333 3.333 1.595
L2-02
Momentary power loss ride-
through time
s 0.5 0.5 0.5 0.5 0.5 0.5
L2-03
Momentary power loss
Baseblock time
s 0.5 0.5 0.5 0.6 0.6 0.7
B.3 Defaults Determined by Drive Capacity (o2-04) and ND/HD (C6-01)
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
221
B
Parameter List
2/6/2008-14:44
