H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description
Mode
V/f
10 Up Command Open: Maintains the current frequency reference
Closed: Increases or decreases the current frequency reference.
Ensure that the increase and decrease commands are set in
conjunction with one another.
O
11 Down Command O
14 Fault Reset
Closed: Resets faults if the cause is cleared and the Run
command is removed.
O
15 Fast-Stop (N.O.)
Closed: Decelerates at the Fast-Stop time C1-09.
To restart the Fast-Stop input must be
released and Run must be
cycled.
O
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time) O
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
O
40
Forward Run Command
(2-Wire sequence)
Open: Stop
Closed: Forward run
Note: Can not be set together with Settings 42 or 43.
O
41
Reverse Run Command (2-Wire
sequence)
Open: Stop
Closed: Reverse run
Note: Can not be set together with Settings 42 or 43.
O
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the
max. output frequency (E1-04) if b3-01 = 0. Activates Speed
Estimation Type Speed search if b3-01 =1.
O
62 External Search Command 2
Closed: Activates Current Detection Speed Search from the
frequency reference b3-01 = 0. Activates Speed
Estimation Type
Speed search if b3-01 =1.
O
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-485/422 interface. O
No. Name Description Range Def.
Mode
Addr.
Hex
Pg.
V/f
H2: Multi-Function Digital Outputs
Use H2 parameters to assign functions to the multi-function digital outputs.
H2-01
Terminal MA,
MB and MC
Function
Selection
(relay)
Refer to H2 Multi-Function Digital Output Settings
on page 208 for a description of setting values.
0 to 13D E O 40B 103
B.2 Parameter Table
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
207
B
Parameter List
2/6/2008-14:44
