Wire Gauge
mm
2
(AWG)
Terminal
Screws
Crimp Terminal
Model Numbers
Tightening Torque
N m (lb to in.)
3.5/5.5 (12/10)
M4 R5.5-4 1.2 to 1.5 (10.6 to 13.3)
M5 R5.5-5 2.0 to 2.5 (17.7 to 22.1)
M6 R5.5-6 4.0 to 5.0 (35.4 to 44.3)
M8 R5.5-8 9.0 to 11.0 (79.7 to 97.4)
8 (8)
M4 8-4 1.2 to 1.5 (10.6 to 13.3)
M5 R8-5 2.0 to 2.5 (17.7 to 22.1)
M6 R8-6 4.0 to 5.0 (35.4 to 44.3)
M8 R8-8 9.0 to 11.0 (79.7 to 97.4)
14 (6)
M4 14-4 1.2 to 1.5 (10.6 to 13.3)
M5 R14-5 2.0 to 2.5 (17.7 to 22.1)
M6 R14-6 4.0 to 5.0 (35.4 to 44.3)
M8 R14-8 9.0 to 11.0 (79.7 to 97.4)
22 (4)
M6 R22-6 4.0 to 5.0 (35.4 to 44.3)
M8 R22-8 9.0 to 11.0 (79.7 to 97.4)
30/38 (3/2) M8 R38-8 9.0 to 11.0 (79.7 to 97.4)
Note: Use crimp insulated terminals or insulated shrink tubing for wiring connections. Wires should have a
continuous maximum allowable temperature of 75 °C 600 Vac UL-approved vinyl-sheathed insulation.
Table C.5 Recommended Input Fuse Selection
Drive Model CIMR-Jo
Class T Fuses
600 Vac, 200 kAIR
Fuse Ampere Rating
200 V Class Single-Phase Drives
BA0001 A6T15 15
BA0002 A6T20 20
BA0003 A6T20 20
BA0006 A6T40 40
BA0010 A6T40 40
200 V Class Three-Phase Drives
2A0001 A6T10 10
2A0002 A6T10 10
2A0004 A6T15 15
2A0006 A6T20 20
2A0008 A6T25 25
2A0010 A6T25 25
2A0012 A6T30 30
2A0018 A6T40 40
2A0020 A6T40 40
400 V Class Three-Phase Drives
4A0001 A6T10 10
4A0002 A6T10 10
4A0004 A6T20 20
4A0005 A6T25 25
4A0007 A6T25 25
C.3 UL Standards
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
237
C
Standards Compliance
